Biogas Compressor

Biogas compressor, also known as biogas recovery compressor, is a kind of biogas recovery and pressurization, and then discharges and stores the biogas according to a certain pressure. The biogas compressor can improve the phenomenon of insufficient biogas pressure, make the biogas burn more fully, and have greater firepower. It is widely used in various biogas digesters and long-distance transportation of biogas. The product is cost-effective, and the exhaust pressure ranges from 0.2MPa to 25MPa. From 0.2Nm³ to 40Nm³, the compressor has Z type, D type, V type and other forms. It is widely used in various biogas digesters and long-distance transportation of biogas

Types Of Biogas Booster Compressor

D Type

DW-6.4-0.4

Price: $60455~$69100

Compressor model: MN-6.4/250

Compressed media: biogas

Structure type: Type DW

Compression stage: Two-stage compression

Nominal volume flow:6.4m3/min

Suction pressure: Atmospheric pressure

Exhaust pressure:2.5Mpa

Cooling method: Air cooling

Equipped power: 132KW

Dimensions (L×W×H) :5900*3100*2550mm

DW-10.7-0.4

Price: $100400~$114700

Compressor model: MN-10.7/250

Compressed media: biogas

Structure type: Type DW

Compression stage: Two-stage compression

Nominal volume flow:10.7m3/min

Suction pressure:Atmospheric pressure

Exhaust pressure:2.5Mpa

Cooling method: Air cooling

Equipped power: 250KW

Dimensions (L×W×H) :4800*1600*1200mm

Z Type

ZW-1.67-30

Price: $100400~$114700

Compressor model: MN-10.7/250

Compressed media: biogas

Structure type: Type DW

Compression stage: Two-stage compression

Nominal volume flow:10.7m3/min

Suction pressure:Atmospheric pressure

Exhaust pressure:2.5Mpa

Cooling method: Air cooling

Equipped power: 250KW

Dimensions (L×W×H) :4800*1600*1200mm

ZW-3.33-20

Price: $11400~$13000

Compressor model: MN-3.33/20

Compressed media: biogas

Structure type: Type ZW

Compression stage: Two-stage compression

Nominal volume flow:3.33m3/min

Suction pressure:Atmospheric pressure

Exhaust pressure:2Mpa

Cooling method: Air cooling

Equipped power: 55KW

Dimensions (L×W×H) :2180*1250*2360mm

V Type

VW-6-3

Price: $28990~$32540

Compressor model: MN-6/3

Compressed media: biogas

Structure type: Type VW

Compression stage: Two-stage compression

Nominal volume flow:6m3/min

Suction pressure:Atmospheric pressure

Exhaust pressure:0.3Mpa

Cooling method: Water cooling

Compressor speed: 740（r/min）

Equipped power: 30KW

Dimensions (L×W×H) :1850*1650*1600mm

Weight: 2500kg

VW-9.8-4

Price: $38925~44470

Compressor model: MN-9.8/4

Compressed media: biogas

Structure type: Type DW

Compression stage: Two-stage compression

Nominal volume flow:9.8m3/min

Suction pressure:Atmospheric pressure

Exhaust pressure:0.4Mpa

Cooling method: Water cooling

Compressor speed: 980（r/min）

Equipped power: 30KW

Dimensions (L×W×H) :1850*1780*1600mm

Weight: 2500kg

VW-40-2.5

Price: $60645~$69290

Compressor model: MN-40/2.5

Compressed media: biogas

Structure type: Type VW

Compression stage: Two-stage compression

Nominal volume flow:40m3/min

Suction pressure:Atmospheric pressure

Exhaust pressure:0.25Mpa

Cooling method: Water cooling

Compressor speed: 980（r/min）

Equipped power: 30KW

Dimensions (L×W×H) :3000*1850*1780mm

Weight: 3500kg

Get Your Compression solution

"Ready to take your compressor project to the next level? Fill out our form now and receive a FREE high-quality compressor solution that will boost your efficiency and productivity. Don't miss out on this opportunity to improve your operations - fill out the form today!"

Purchase now

The difference between biogas compressor and other compressors

The biogas compressor unit includes compressor host, motor, coupling, piping system, cooling system, electrical equipment, and auxiliary equipment.

Good air tightness: strict air tightness detection from air inlet to air outlet, no air leakage.
Large flow rate, from 0.3 m3/min to 90 m3/min. You can choose different models according to your needs.
Long Life: gas circuit and circuit strictly separated, Gas rich in water will not affect the electrical life
Good maintainability: can repair it yourself with simple tools and accessories
Explosion-proofMotors
The pressure and flow can be adjusted within a certain range

NO	model	Exhaust volume m3/h	Inlet pressur Mpa	Outlet pressure Mpa	Motor power kw	Dimension mm
1	VW-1.67/6	100	Atmospheric pressure	0.6	11	16808001300
2	VW-0.83/250	50	Atmospheric pressure	25	30	16808001300
3	VW-6/3	6	Atmospheric pressure	0.3	30	1850x1650x1600
4	DW-6.5/0.035-8	6.5	0.0035	0.8	45	1850x1780x1600
5	VW-9.8/4	9.8	Atmospheric pressure	0.4	45	1850x1780x1600
6	VW-40/2.5	40	Atmospheric pressure	0.25	132	3000x1850x1780
8	VW-0.67/1-250	80	0.1	25	30	16808001300
9	ZW-1.5/0.1-250	100	0.01	25	30	210011701960
10	ZW-1.67/30	100	Atmospheric pressure	3	30	210011701960
11	ZW-3.33/20	200	Atmospheric pressure	2	55	218012502360
12	ZW-4/80	240	Atmospheric pressure	8	75	210011701960
13	ZW-3.2/ 0.3-50	250	0.03	5	55	210011701960
14	ZW-2.3/04-250	200	0.04	25	75	218012502360
15	ZW-6/50	360	Atmospheric pressure	5	90	315013502360
16	ZW-5/150	300	Atmospheric pressure	15	110	315013502360
17	ZW-5/0.2-250	360	0.02	25	110	315013502360
18	ZW-3.34 /1-250	400	0.1	25	132	350021002300
23	DW-6.4/0.4-250	800	0.04	25	132	590031002550
24	DW-10.7/0.4-250	900	0.04	30	250	480016001200
25	DW-18/250	1080	Atmospheric pressure	25	320	600016001200

Inspection work before starting:

Check whether the lubricating oil level of the main oil tank is normal and whether the oil quality is normal. (100# compressor oil in winter, 150# in summercompressor oil)

Check whether the oil level of the oiler is normal
Check whether the body bolts are loose or not.
Check and open the main inlet and outlet valves of cooling circulating water and the inlet and outlet valves of each cooler. Control pressure 20.2MPa. Check whether the instrument air pressure is within the index of 0.4-0.8MPa, and check to open the intake valve.

Manually turn the car to check whether the main engine is jammed
Check and open the valve of the oil discharge water system

Benifits

Good air tightness: Strict air tightness testing is carried out from the air inlet to the air outlet, no air leakage, no leakage under 6.8KPa pressure.
Acid and alkali resistance: The passage from the air inlet to the air outlet is made of acid and alkali resistant plastic or rubber parts, which can pass weak corrosive gases rich in water vapor.
Long service life: The gas circuit and circuit are strictly separated, and the electrical life will not be affected by the gas rich in water vapor.
The structure is simple; there is no external pipeline between the two symmetrical air chambers.
Good maintainability: It can be repaired by yourself with simple tools and accessories.
High utilization rate, saving cost and increasing income.
The whole machine has the characteristics of low noise, high stability, simple structure, convenient maintenance, etc., and the product is reliable.

We Serivice for many customer

Minuo offers independent solutions according to flow/purity/pressure, usage environment, main application, and special customer requirements at a competitive prices. Our compressor booster is made of high-quality materials and has been tested thoroughly to ensure the best quality.

Get Your Free Solution

Biogas compressors are an important part of the biogas production process. They help to reduce the volume of biogas, making it easier to store and transport. At Minnuo, we offer a wide range of biogas compressors to meet your needs. Our compressors are designed to be reliable, efficient and economical. To find the perfect biogas compressor for your needs, simply fill out our website form and one of our experts will contact you to discuss your requirements.
